A multi-use games area, or MUGA, is designed to host several different sports on one surface, from netball and basketball to tennis and five-a-side football. That flexibility is the whole point of a MUGA, and it rests almost entirely on the line marking.
Marking a single sports court to the right standard is exacting work in itself. Marking three or four onto the same surface, so that each one is correct and none of them causes confusion, is a genuinely specialist job. It calls for accurate setting out, a clear plan for colour, and a good understanding of what each sport's governing body expects.
What a multi-use games area is.
A MUGA is a hard or synthetic surface laid out for more than one sport at the same time. Rather than building a separate court for each activity, the space is marked once with several overlaid sets of lines, each belonging to a different game. A typical MUGA might carry netball, basketball, tennis and a five-a-side pitch, all sharing the same tarmac or polymeric surface.
You will find them at schools, leisure centres, parks and housing developments, anywhere that needs to offer a range of sport without the land or budget for individual courts. Sport England and SAPCA, the Sports and Play Construction Association, publish the guidance the industry works to, and common MUGA sizes fall around 38 metres by 18 metres, or 35 metres by 17 metres, depending on the sports the area is built for. The sports you choose decide the size, because the dimensions are led by the largest court in the set.
Why marking several courts on one surface is harder than it looks.
On a single court, the lines have the surface to themselves. On a MUGA, several regulation courts have to coexist in the same space without any of them being compromised. Each court still has to be the correct size and shape for its sport, and each line still has to sit exactly where the governing body says it should.
The difficulty is that these courts overlap. A tennis baseline might run close to a netball third line, and a basketball key can sit inside the footprint of another court entirely. Getting one court right is straightforward. Getting all of them right, on the same surface, so that a player of any of the sports sees a correct and complete court, is where the skill lies.
Getting the dimensions right.
Every sport on a MUGA is governed by a national or international body, and each sets out precise dimensions. A full tennis court measures 23.77 metres long and 10.97 metres wide for doubles, following LTA and ITF guidance. A netball court, to England Netball, is 30.5 metres by 15.25 metres, divided into three equal thirds with a shooting circle at each end. A senior basketball court, to England Basketball and FIBA, is 28 metres by 15 metres. Badminton, where it is included, is smaller again at 13.4 metres by 6.1 metres for doubles.
Line widths matter too. A width of 50 millimetres is standard across tennis, netball and basketball, with badminton slightly narrower at around 40 millimetres. These are not details to be estimated on site. A court marked a few centimetres out, or with lines the wrong width, produces a surface that looks finished but does not actually meet the standard for proper play.
Colour, and keeping the lines readable.
With several courts sharing one surface, colour is what stops a MUGA becoming a confusing tangle of lines. Each sport is given its own colour, so a player can pick out the court they need and ignore the rest. The primary sport, the one the area is used for most, is usually marked in the most prominent colour, with the others in supporting shades.
There is a balance to strike. The lines have to be distinct enough to tell apart at a glance, while the surface as a whole still needs to look ordered rather than chaotic. Planning the colour scheme before any marking begins, and agreeing which sport takes priority, is a large part of what makes a finished MUGA usable rather than just technically correct.
Which colour goes with which sport.
There is no law that forces a sport to be marked in a set colour, but there are well-established recommendations, and following them keeps a multi-sport surface easy to read. The guiding principle is contrast: the lines have to stand out from the surface and from the other courts sharing it. On a court used for a single sport that usually means white, but on a shared surface each sport is given its own recommended colour so the overlapping sets of lines can be told apart at a glance.
For an outdoor multi-sport surface, the colours usually recommended are:
- Football. Green, which reads clearly on tarmac and leaves the brighter colours free for the smaller courts.
- Tennis. Yellow, which stands out well against green or blue surfaces, though white remains the traditional choice on a dedicated tennis court.
- Netball. Red, so its circles and thirds stay easy to separate from the other markings.
- Basketball. Orange, which gives a strong contrast that is not easily confused with the other sports.
Indoor sports halls follow their own established colour code, which is not always the same, and the colour of the surface can shift any of these choices. The priority throughout is that the primary sport takes the clearest, most prominent colour, and every other set of lines is chosen to stand apart from it. Agreeing this scheme at the planning stage, rather than on the day of marking, is what keeps a busy multi-sport surface readable for everyone who uses it.
The surface and the materials.
MUGAs are usually laid in either macadam, a tarmac-style surface, or a synthetic polymeric one, and the markings are chosen to suit. On a well-prepared surface, court lines can be applied in a durable paint system or in thermoplastic, which is melted onto the surface and stands up well to heavy, repeated use.
Whichever is specified, the surface has to be sound and properly prepared first. A marking is only ever as good as the surface beneath it, and a court marked over a worn or poorly prepared surface will not hold up, however carefully the lines are set out. Grip matters as well, since these are surfaces people run and turn on, so slip resistance belongs in the specification rather than being treated as an afterthought.
Planning, setting out and keeping it right.
A good MUGA marking job starts well before any paint or thermoplastic goes down. The sports are confirmed, the layout is planned so every court fits correctly, the colours are agreed, and the surface is checked and prepared. The setting out, measuring and marking each court accurately from fixed reference points, is the stage that decides whether the finished area is right.
Markings also wear over time, particularly on a surface in constant use, and on a MUGA a faded line is easy to misread against the others. Reviewing the markings periodically and refreshing them before they become unclear keeps the area safe, usable and correct for every sport it was built for.
Conclusion.
Marking a multi-use games area is a good deal more involved than painting lines on tarmac. It means fitting several regulation courts onto one surface, each accurate to its governing body, each clear in its own colour, and all of them coexisting without confusion. Done well, it turns a single area into a genuinely flexible sports facility. Done poorly, it produces courts that look right but do not play right.
It is specialist work, and it rewards planning, accurate setting out and a proper understanding of the standards involved. If you are considering a new MUGA, or looking at markings that have seen better days, it is worth involving someone who marks these areas regularly and knows what each sport requires.
